To make sure this part does fit your vehicle Check The Fit
Axle Bearing And Hub Assembly - Crs - Wheel Bearing And Hub Assembly (Part Number: NT515054)
- Life Cycle Status Code: 2
- Life Cycle Status Description: Available to Order
- ABS Connector Shape: Oval
- ABS Ring Type: Tone Ring
- ABS Sensor Ring Included: Yes
- Bearing Type: Taper
- Center Bore Diameter: 139.7mm
- Center Bore Diameter: 5.500 in.
- Driven or Non-Driven: Non-Driven
- Flange Bolt Size: 2.13385826771654 in.
- Flange Bolt Size: 54.2mm
- Flange Bolt Thread Size: M14X1.5
- Flange Offset: 49.8mm
- Flange Offset: 1.96062992125984 in.
- Flange Type: Triangle
- Gasket Or Seal Included: Yes
- Hub Height: 146mm
- Hub Height: 5.74803149606299 in.
- Hub Pilot Diameter: 99.3mm
- Hub Pilot Diameter: 3.90944881889764 in.
- Lug Bolt Thread Size: M14X1.5
- Lug Number: 6
- Material: Steel
- Mounting Bolts To Knuckle: 3
- New Or Remanufactured: New
- Spline Count: N/A
- Terminal Gender: Female
- Wiring Harness Included: Yes
- Wiring Harness Length: 29.7244094488189 in.
- Wiring Harness Length: 755mm
- Extended Product Description: Wheel Bearing And Hub Assembly
- Marketing Description: Manufactured to OEM specification.
- Short Product Description: WhlBearingandHubAssy
- Manufacturer:
- Crs
- Part Number:
- NT515054
- Manufacturer Part Number:
- NT515054
- Description:
- Axle Bearing And Hub Assembly
- Long Description:
- Wheel Bearing And Hub Assembly
- Part Type:
- Axle Bearing And Hub Assembly
- Category:
- Driveline And Axles
- Subcategory:
- Hubs And Related Components
- Warehouse Notes:
- AXLE BEARING AND HUB - FRONT HUB ASSEMBLY
- Sales Rank:
Product Details
- Condition:
- New
- Product Fit:
- Direct Fit
- Weight:
- 8.791 lbs.
- Height:
- 6.006"
- Width:
- 7.047"
- Length:
- 7.047"
- UOM:
- EA
- Quantity Sold:
- Sold individually
- Qty Per Application:
- 1
- Minimum Order Qty:
- 1
- Position:
- Front
Technical Details
- Life Cycle Status Code
- 2
- Life Cycle Status Description
- Available to Order
- ABS Connector Shape
- Oval
- ABS Ring Type
- Tone Ring
- ABS Sensor Ring Included
- Yes
- Bearing Type
- Taper
- Center Bore Diameter
- 139.7mm
- Center Bore Diameter
- 5.500 in.
- Driven or Non-Driven
- Non-Driven
- Flange Bolt Size
- 2.13385826771654 in.
- Flange Bolt Size
- 54.2mm
- Flange Bolt Thread Size
- M14X1.5
- Flange Offset
- 49.8mm
- Flange Offset
- 1.96062992125984 in.
- Flange Type
- Triangle
- Gasket Or Seal Included
- Yes
- Hub Height
- 146mm
- Hub Height
- 5.74803149606299 in.
- Hub Pilot Diameter
- 99.3mm
- Hub Pilot Diameter
- 3.90944881889764 in.
- Lug Bolt Thread Size
- M14X1.5
- Lug Number
- 6
- Material
- Steel
- Mounting Bolts To Knuckle
- 3
- New Or Remanufactured
- New
- Spline Count
- N/A
- Terminal Gender
- Female
- Wiring Harness Included
- Yes
- Wiring Harness Length
- 29.7244094488189 in.
- Wiring Harness Length
- 755mm
- Extended Product Description
- Wheel Bearing And Hub Assembly
- Marketing Description
- Manufactured to OEM specification.
- Short Product Description
- WhlBearingandHubAssy
Specifications
The CRS Axle Bearing And Hub Assembly contains no remanufactured components, and is designed to operate in either city or highway driving.
| Year | Make | Model | Engine | Notes |
|---|---|---|---|---|
| 2003 | Chevrolet | Silverado 1500 | 4.3L | Front; RWD; Quantity needed per vehicle: 2 |
| 2003 | Chevrolet | Silverado 1500 | 4.3L | Front; RWD; Quantity needed per vehicle: 2 |
| 2003 | Chevrolet | Silverado 1500 | 4.8L | Front; RWD; Quantity needed per vehicle: 2 |
| 2003 | Chevrolet | Silverado 1500 | 5.3L | Front; RWD; Quantity needed per vehicle: 2 |
| 2003 | Chevrolet | Silverado 1500 | 5.3L | Front; RWD; Quantity needed per vehicle: 2 |
